Humidity Control Electronic Dry Storage Cabinet , Liquid Crystal
Glass Board
Applications:
Its typical applications include the prevention and protection
against all types of oxidation (rust), the prevention of the growth
of fungus on optics, the dry preservation of lab materials and
samples as well as the protection of MSDs (moisture sensitive
devices) as per IPC/JEDEC J-STD-033 within the electronics
industry.
Suitable for storing: Semiconductors, IC packages, PCBs, Silicon
Wafers, Ceramics , Liquid Crystal Glass (LCG) Board, Optical Fiber,
CCD etc, Crystal Resonator.
Specifications:
Ultra Low Humidity Type-Single Door Type
Cabinets suitable for processing and storage of electronic
components.
RH Range:0-5% For Industrial use
Model :DC87185L |
Outside:W598*D710*H1910mm |
Inside:W596*D682*H1723mm |
Sheet:5pcs, Each with 100kg loading |
Power:85V-265V, 50HZ/60HZ |
Weight: 85kg Capacity:718L |
LED Display:yes(Honeywell) |
Ultra Low Humidity Dehumidifier Cabinet |
ELECTRONIC COMPENENT USE |
Features: |
1)Humudity adjustable, energy saving design digital LED-Honeywell
display and control, all the setting can be justified at the touch
of the UP and DOWN bottom. |
2)1.0mm thickness steel body, rustproof paint, 3.2mm toughened
glass. |
3)Moisture absorbs continuously with sustention for 24hours |
4)Equipment with high performance, reliable desiccators and
himidity controller located at the lower deep inside. |
5)Zinc alloy lock with plus pressure capability. Anti-ESD powder
coating, dark green look.Surface powder coating with RoHS
certification.On the base truckle with brake . |
6)Slip layer board make the inter space adjustable. |
7)Energy saving design: low electricity consumption resuegence, no
heating, no condensation Dripping, absence of fan noise. |
Remarks:
All models can be chosed stainless material.
With casters on the base
Can choose Anti-ESD dark green color.
Customized size accepted
Digital Temp Display & RH Control
Power supply direct connection
No need of battery
Digital LED-Honeywell display and control, with UP and DOWN bottom.
Competitive Advantage:
Energy saving design: low electricity consumption resuegence, no
heating, no condensation Dripping, absence of fan noise
Dual digital hygrometer-Ecology Design
Noisy free, vibration free, low humidity keeping at ambient
temperature and long-term consecutive driving.
Energy saving design: maintenance cost is only a very little
electricity. It comes with humidity controller.
No expendable supplies (Exchange free desiccant), very economical.
No use of batteries for hygrometer.
Long lasting and highly reliable.
With detachable shelves, wide space is available to use.
With high technology( photocatalyst, IC timer, shape-memory alloy
and dual digital hygrometer)
| RH: 01-5% | | | | | | | |
| Model | Door type | Overall Size H×W×D(mm) | Interior size H×W×D(mm) | Sheet | Capacity (L) | Voltage | Average Power (W) | N.W. |
| (KG) |
| DC8985L | 1,manual | 688×488×400 | 598×446×372 | 1 | 98 | 85V-265V | 18 | 20 |
| 50Hz/60Hz |
| DC81605L | 1,manual | 1313×598×400 | 1151×596×372 | 3 | 160 | 85V-265V | 20 | 31 |
| 50Hz/60Hz |
| DC82405L | 1,manual | 1310×598×400 | 848×596×372 | 3 | 240 | 85V-265V | 20 | 43 |
| 50Hz/60Hz |
| DC85405L | 1,manual | 1310×598×710 | 848×596×682 | 3 | 540 | 85V-265V | 60 | 70 |
| 50Hz/60Hz |
| DC87185L | 1,manual | 1910×598×710 | 1723×596×682 | 5 | 718 | 85V-265V | 60 | 85 |
| 50HZ/60HZ |
| DC83205L | 2,manual | 1010×900×450 | 848×898×422 | 3 | 320 | 85V-265V | 40 | 54 |
| 50HZ/60HZ |
| DC84355L | 2,manual | 1010×900×600 | 848×898×572 | 3 | 435 | 85V-265V | 40 | 60 |
| 50HZ/60HZ |
| DC88705L | 2,manual | 1895×900×600 | 1700×898×572 | 3 | 870 | 85V-265V | 80 | 106 |
| 50HZ/60HZ |
| DC814365L-6 | 6,manual | 1910×1200×710 | 1723×1198×682 | 5 | 1436 | 85V-265V | 120 | 147 |
| 50HZ/60HZ |
| DC814365L-4 | 4,manual | 1910×1200×710 | 1723×1198×682 | 5 | 1436 | 85V-265V | 120 | 147 |
| 50HZ/60HZ |
